Name Onego Rio
Flag
Dutch
Callsign
PBYD
Class
DNV/GL
Type
Multi Purpose Singledeck/Tweendeck Box-shaped Open-hatch
GT / NT
7576 / 3835
DWAT Summer
10350 mt
DWCC Summer (abt.)
9300 mt
Summer Draft
7.34
LOA
142.70
Beam
18.25
Moulded depth
10.15
ME / Bowthruster
4320 kW / 500 kW
IMO Number
9258985
Type of hatchcovers
Pontoon
Gear
2 x 80mt port side cranes, combinable upto 150 mt
IFO / MDO capacity
530 cbm / 150 cbm
Tanktop strength
Tanktop 18 mt per sqm
Tweendeck 3.5 mt per sqm
Hatchcover 1.75 mt per sqm
P&I Club
British Marine
Speed
abt 12.5 kts
Ice Class
None
Hatch Sizes
No. 1
38.95
13.15
No. 2
65.41
13.15
Hold dimensions
L
B
H
Grain
Bale
No. 1
38.95
13.15
11.05
No. 2
65.41
13.15
11.05
Total capacity cbm
14698
14335
Total capacity cbft
519059
505840

Disclaimer

The vessel specifications contained in this data sheet have been compiled to the best of Onego Shipping and Chartering B.V. knowledge. However, all specifications contained in this data sheet only describe “about” data and therefore cannot be considered as guaranteed specification of the respective vessel. Speed and consumption figures may vary from the data contained in this data sheet and are dependent on weather and sea conditions, the loaded cargo and the quality of the bunker on board. The loading and lifting capacities of the vessels are subject to the vessel’s stability, trim, permissible weights, regulations of visibility and might depend on the cargo and/or ballast on board. None of the details set out in this data sheet shall be part of charterparties or other agreements between Onego Shipping and Chartering B.V., including its affiliates, and any third party.
